Features
K Media and R Media
- Temp (continuous): min -15°F (-26°C) max 220°F (104°C)
- Filter change out differential: 15 - 20" H2O over initial ΔP
- Dust loading capacity is increased 40% - 50% with prefilter
- 99%+ removal efficiency standard to 5 micron
Options
- Polyester - 1, 4, 25 & 100 micron
- HEPA - 99.97% D.O.P. efficiency to 0.3 micron
- Stainless Steel Nomex: High temperature Nomex cloth - 99+% efficient, reinforced by stainless steel wire mesh & expanded metal
Endcap Styles
- G = Galvanized metal
- M = Molded plastisol
- N = Neoprene blended gasket on open endcaps
- SS = Stainless steel
Applications
- Pneumatic Conveying Systems
- Power Plants
- Specifications
- Documents
| Model | Price |
|---|---|
| 235R | $367.00 |
| 851R | $285.00 |
| 850R | $226.00 |
| 849R | $146.00 |
| 848R | $127.00 |
| 843R | $83.00 |
| 842R | $59.50 |
| 685R | $3,785.00 |
| 485R | $3,045.00 |
| 484R | $2,145.00 |
| 385R | $2,315.00 |
| 384R | $1,690.00 |
| 377R | $1,720.00 |
| 376R | $1,240.00 |
| 375R | $1,160.00 |
| 374R | $796.00 |
| 345R | $893.00 |
| 31K | $109.00 |
| 30K | $88.00 |
| 275R | $769.00 |
| 274R | $583.00 |
| 245R | $638.00 |
| 245K | $532.00 |
| 244R | $399.00 |
| 244K | $311.00 |
| 231K | $208.00 |
| 230K | $151.00 |
| 19K | $74.50 |
| 18K | $51.00 |
| 15K | $47.40 |
| 14K | $34.70 |
| 235K | $305.00 |
