Features
- Pleated media for high dirt holding capacity
- Polyester: reinforced with epoxy coated steel wire on both sides of cloth, expanded metal I.D.
- Paper: heavy duty industrial strength paper surrounded by galvanized expanded metal O.D.
Technical Specifications
Technical Specifications
- Polyester: 99+% removal efficiency to 5 microns
- Paper: 99+% removal efficiency to 2 microns
- Temp (continuous): min -15°F (-26°C), max 220°F (104°C)
- Filter change out differential: 15-20” H2O over initial ΔP
Options
Polyester Media Benefits/Specs
- Reduced maintenance due to longer durability
- Heavy duty
- Moisture resistant
- Washable with luke warm water and mid detergent
Paper Media Benefits/Specs
- Cost effective
- Industrial Strength
- Gently blow out media
Endcap Styles
- B = Closed one end w/bolt hole
- C = Closed one end
- E = EPDM gasket
- F = Felt gaskets on open endcaps
- G = Galvanized metal
- H = Felt gasket on bolt hole
- M = Molded plastisol
- N = Neoprene blended gasket on open endcaps
- R = Mixed rubber/cork gasket on open endcaps
