Features
- Corrosive resistant blue powder coat carbon steel
- Integrated baffle
- Expansion chamber
- 1/4” NPSC inlet/outlet taps (select models)
- 1” NPSC drain and sight port (1" BSPP)
- Simplified vacuum package: 2 functions in 1 (liquid separator & inlet air filter)
- Significant liquid/slurry holding capacity
- Prevents emulsification of oil in oil lubricated systems
Technical Specifications
- Vacuum Rating: rough to medium vacuum service*
- Filter change out differential: 15-20" H2O (37-50 mbar) over initial Δ P
- Polyester: 99%+ particulate removal efficiency to 5 micron
Options
- ASME rated vessels
- Stainless steel construction & various finishes
- Various media
- Extended bucket for additional holding capacity
- Preseparator stainless steel demister
- Vacuum gauges
- Drain packages
- Support legs
- For larger flows, ask about our Knockout Separator Series
Applications
- Chemical Processing
- Pharmaceutical Industry
- Vacuum Pumps & Systems
- Food Processing
- Chip Processing
- Air process systems to separate water or solvents before air reaches the pump
- Specifications
- Documents
| Model | Price |
|---|---|
| LRS-275-DN150 | Contact for Price |
| LRS-275-DN100 | Contact for Price |
| LRS-275-600F | $3,465.00 |
| LRS-275-400F | $2,970.00 |
| LRS-237-301HC | Contact for Price |
| LRS-237-300C | $2,040.00 |
| LRS-237-251HC | Contact for Price |
| LRS-237-250C | $1,965.00 |
| LRS-237-201HC | Contact for Price |
| LRS-237-200HC | $1,930.00 |
| LRS-19-151HC | Contact for Price |
| LRS-19-150HC | $999.00 |
| LRS-19-126HC | Contact for Price |
| LRS-19-125HC | $980.00 |
| LRS-19-101HC | Contact for Price |
| LRS-19-100HC | $980.00 |
| LRS-19-075HC | $980.00 |
