• Fully drawn carbon steel weatherhood (3” to 6” connections only)
• Multiple silencing features to reduce and deaden sound
• Tubular Silencing: tubes placed to maximize attenuation
• Quiet Band Support: “Quiet band” technology utilizes sound suppression in the design of the housing
• Internal Silencer: center tubular silencer
• 1/8” tap hole (standard on 2G series)
• Temp (continuous): min -15°F (-26°C) max 220°F (104°C)
• Filter change out differential: 15-20" H₂O (37‐50 mbar) over initial Δ P
• Polyester: 99%+ removal efficiency standard to 5 micron
• Paper: 99%+ removal efficiency standard to 2 micron

Application

• Blowers-Centrifugal
• Blowers-Regenerative
• Blowers-Side Channel
• Vacuum Lifters
• Vacuum Pump-Regenerative

Options

• Pressure drop indicator
• Various media
• Stainless steel construction
• Various finishes and connection styles
• Side Access Filter Silencers (LQB Series) available for space restricted enclosures (select models)
