| Model | 345P™ |
| Flow (SCFM) | 1100 |
| Media | Polyester |
| Micron rating | 5.0 |
| Qty per box | 2 |
| Case quantity | 4 |
| Outer dimension | 9.75 in |
| Inner dimension | 6 in |
| Height | 14.43 in |
| Surface area | 22.1 in |
- Rated for 99+% removal efficiency
- Available ratings include 1, 4, 5, 10, 25, and 100 microns
- Wire mesh reinforced support structure and rigid expanded metal core for improved strength and rigidity in heavy-duty applications
- Needle-felt media that offers exceptional particle capture characteristics and very low restriction to air flow
Options
- Polyester/Paper Media with SS ID/OD, J Series (select sizes)
- Polyester/Paper Media with SS ID/OD, Food Grade Silicone Endcaps, K Series (select sizes)
- Polyester/Paper Media with SS ID/OD/EC, Q Series (select sizes)
- Polyester/Paper Media with SS ID/OD/EC, Silicone Endcap Adhesive, R Series (select sizes)
- Atex Certification (select models)
- Various gaskets or potting compounds
Endcap Styles
- B = Closed one end with bolt hole, open on other end
- C = Closed one end, open on other end
- G = Galvanized metal
- M = Molded plastisol
- F = Felt gaskets on open endcaps
- N = Neoprene blended gasket on open endcaps
- R = Mixed rubber/cork gasket on open endcaps
