| Model | DSV-PSG725/AC10-NW25 |
| Connection type | ISO Flange |
| Flow (SCFM) | 12 |
| Dimension a | 8.4 in |
| Dimension b | 0.87 in |
| Dimension c | 0.87 in |
| Dimension d | 4.15 in |
| Dimension e | 4 in |
| Weight | 3 lb |
| Media | Coalescing |
| Micron rating | 0.3 |
| Qty per box | 1 |
| Case quantity | 1 |
- Corrosive resistant white powder coat carbon steel
- Primary filter captures and coalesces oil entrained in air stream
- Activated carbon element removes offensive odors generated by the process
- Convenient access drain port
- Back pressure valve designed to release pressure at 7.35 psig. (0.5 bar) differential for pump safety (DEE Series)
Options
- Clamp, centering ring, and o-ring kit for inlet/outlet
- Back pressure valve (DEE Series)
- Drain kits available upon request (DSV Series)
