Imperial Metric
Model HDL-PSG474/2-501
Outlet size 5 in
Connection type BSPT
Flow (SCFM) 800
Dimension a 36.5 in
Dimension b 11 in
Dimension c 18.5 in
Dimension e 22 in
Weight 150 lb
Media Coalescing
Micron rating 0.3
Qty per box 1
Case quantity 1
Replacement element PSG474-2
HDL-PSG474/2-501 tech specifications
  • Captures oil fog, mist or aerosol from exhaust of oil sealed vacuum pumps
  • Waste oil can be recycled
  • Pleated filter element provides increased surface area for low back pressure separation of ultra-fine oil mists
  • Seamless drawn housings (1" - 2.5" connections)
  • O-ring sealed housings
  • Corrosive resistant white powder coat carbon steel
  • Discharge baffle (1" - 2.5" connections)
  • 1/4” NPSC drain tap (1" - 2.5" connections)
  • 1/2” NPT drain tap (3" - 8" connections​)

Application

  • Blower Exhaust Oil Mist
  • Cement
  • Food Processing-Pressure
  • Nailers/Staplers
  • Paper Processing
  • Vacuum Coating
  • Vacuum Freeze Dry
  • Vacuum Outgassing
  • Industrial Vacuum Processes
  • Oil removal for pressure unloading vents on piston compressors
  • Captures oil fog, mist, or smoke from exhaust on oil flooded vacuum pumps
  • Any application requiring low delta p coalescing of large air volumes

Options

​​

  • Lower back pressure media
  • Application specific gaskets/seals
  • Custom connections
  • Various finishes
  • Stainless steel housings (select models)
  • Nameplate bracket (3" - 8" connections​)
  • Lifting lugs (3" - 8" connections​)
