| Model | HDL-PSG860/1-200HC |
| Outlet size | 2 in |
| Connection type | NPSC |
| Flow (SCFM) | 175 |
| Dimension a | 17.42 in |
| Dimension b | 4.59 in |
| Dimension c | 8.93 in |
| Dimension e | 15 in |
| Weight | 30 lb |
| Media | Coalescing |
| Micron rating | 0.3 |
| Qty per box | 1 |
| Case quantity | 2 |
| Replacement element | PSG860-1 |
- Captures oil fog, mist or aerosol from exhaust of oil sealed vacuum pumps
- Waste oil can be recycled
- Pleated filter element provides increased surface area for low back pressure separation of ultra-fine oil mists
- Seamless drawn housings (1" - 2.5" connections)
- O-ring sealed housings
- Corrosive resistant white powder coat carbon steel
- Discharge baffle (1" - 2.5" connections)
- 1/4” NPSC drain tap (1" - 2.5" connections)
- 1/2” NPT drain tap (3" - 8" connections)
Application
- Blower Exhaust Oil Mist
- Cement
- Food Processing-Pressure
- Nailers/Staplers
- Paper Processing
- Vacuum Coating
- Vacuum Freeze Dry
- Vacuum Outgassing
- Industrial Vacuum Processes
- Oil removal for pressure unloading vents on piston compressors
- Captures oil fog, mist, or smoke from exhaust on oil flooded vacuum pumps
- Any application requiring low delta p coalescing of large air volumes
Options
- Lower back pressure media
- Application specific gaskets/seals
- Custom connections
- Various finishes
- Stainless steel housings (select models)
- Nameplate bracket (3" - 8" connections)
- Lifting lugs (3" - 8" connections)
