Features
- Easy maintenance due to see through bucket (ST Series)
- Compact design for space restrictions; min. service area
- Inlet above element for extended element life &
maintenance intervals - Corrosive resistant cast aluminum top with machined
connections and integrated baffle design - Black powder coat carbon steel drop down bucket (CT)
- Shatter-resistant polycarbonate drop down bucket (ST)
Technical Specifications
- Vacuum Rating: medium vacuum service*
- Temp (continuous): min ‐15°F (‐26°C) max 220°F (104°C)
- Filter change out differential: 15-20" H2O (37‐50 mbar) over initial Δ P
- Polyester: 99%+ removal efficiency standard to 5 micron
- Paper: 99%+ removal efficiency standard to 2 micron
Options
- Vacuum gauge
- Taps for gauge and mounting brackets
- Swing bolts for heavy duty environments
- Drain ports
- Extended bucket (select CT models)
- Various finishes (CT)
- Various media
- Reverse pulse configuration
- Spool piece extender (select ST models)
Applications
- Ash Handling
- Cement
- Compressor-Piston
- Envelope Manufacturing
- Factory Automation
- Glass, Ceramic-Vacuum
- Paper Processing
- Pneumatic Conveying Systems
- Vacuum Packaging
- Vacuum Systems-Central
- Waste Water Aeration
- Woodworking
- Intake Suction Filters
- Remote Installations for Piston and Screw Compressors
